## World Earth Day — How accurate were EXXON predictions about Global Warming? [UPDATE : INTEL TODAY predictions for 2040]

January 24 2022 — In the early 80s, oil companies like Exxon and Shell carried out internal assessments of the carbon dioxide released by fossil fuels, and forecast the planetary consequences of these emissions. How accurate were those predictions? Short answer: very good. And if they had not made a silly mistake — never reported before — the Exxon predictions would have been amazingly correct. PS — Please, keep in mind that in those years, the CIA expected a new ice age! Obviously, Corporate Intelligence beats the Central Intelligence Agency. Follow us on Twitter: @INTEL_TODAY

RELATED POST: Earth Day 2021 — CIA : “Climatological Research as it Pertains to Intelligence Problems”

RELATED POST: On This Day — US Surgeon General Report Links Tobacco and Cancer (January 11 1964) [Disinformation : Why does it work?]

UPDATE (April 22 2022) — World Earth Day is a reminder for mankind to protect and safeguard the mother earth and its species, to make Earth a better place for the coming generations. April 22 2022 marks 52 years of Earth Day.

As a wise guy famously said: “Prediction is very difficult, especially if it’s about the future!”

Yet, in the early 80s, EXXON scientists made very accurate predictions about future atmospheric carbon dioxide concentrations and the rise of Earth average temperature.

Some people argue that such kind of predictions usually fail because our planet is too complicated to be predicted with accuracy. Maybe…

But the task is obviously not impossible. Here is the trick. If you wish to be good at predicting the future, you must ban all prejudices from your equations.

And of course, predictions — even if accurate — are completely useless if you cannot communicate them in simple, clear and unambiguous terms. Remember: Humans are wired to avoid uncertainty.

Data Input — The U.S. Energy Information Administration (EIA) is the principal agency of the U.S. Federal Statistical System responsible for collecting, analyzing, and disseminating energy information to promote sound policy making, efficient markets, and public understanding of energy and its interaction with the economy and the environment.

Their past estimates and predicted CO2 emissions are listed in columns 2 and 3 in in billion metric tons.

From these data and predicted emissions, future atmospheric carbon dioxide concentrations can be safely calculated. (Column 5)

Global Temperature prediction — Finally, from these predicted carbon dioxide concentrations, one can make a prediction regarding according to the simple model explained in this post. (Column 6)

In conclusion, INTEL TODAY predicts that Earth average temperature will rise by about 0.12° C every five years until 2040.

PS — Keep in mind that this is the temperature rise above the 1951-1980 average. The rise of temperature relative to pre-industrial era is obtained by adding 0.16° C.

Thus, Intel Today predicts that the Earth average temperature will rise by 1.5° C relative to pre-industrial era in 2040.

A catastrophic event, such as a major volcanic eruption or a nuclear war, could of course alter this scenario. Happy Earth Day!

END of UPDATE

In 1982, Exxon predicted that CO2 levels would reach around 540 parts per million by 2060 and that this concentration would push the planet’s average temperatures up by 2°C over 1980 level.

These predictions have been reported in the media. [For instance : THE GUARDIAN — Shell and Exxon’s secret 1980s climate change warnings]

But the media have always avoided answering the obvious question. How accurate were those predictions?

Atmospheric CO2

The graph show monthly mean carbon dioxide measured at Mauna Loa Observatory, Hawaii. NOAA started its own CO2 measurements in May of 1974, and they have run in parallel with those made by Scripps since then.

Exxon prediction — In 1980, the level of atmospheric CO2 was about 340 ppm (V). Exxon predicted that this level would increased by an am mount 80 ppm over the next 40 years.

2020 Data — From 1980 to 2020, atmospheric CO2 increased by an amount 74 ppm to reach a value of 414 ppm.

This prediction is amazingly correct, being about 10% higher that the data obtained 40 years later!

Earth Global Temperature — NASA

This graph illustrates the change in global surface temperature relative to 1951-1980 average temperatures. This research is broadly consistent with similar constructions prepared by the Climatic Research Unit and the National Oceanic and Atmospheric Administration.

Exxon prediction — Exxon noted that the most widely accepted science at the time indicated that doubling carbon dioxide levels would cause a global warming of 3°C.

Therefore, based on their expectation of the CO2 increase, Exxon predicted a rise of about 1.0° Celsius by year 2020.

2020 Data — From 1980 to 2020, global temperature has increased by about 0.8° C.

This prediction is also very good, but it overestimates the real increase in temperature by 25%.

Half of this overestimate follows from the fact that they had predicted a value of CO2 level 10% too high.

The other half is simply a mistake, as I explain in a technical section below. (See: Radiative forcing)

Conclusions

The predictions of the Exxon paper are amazingly accurate. Would you dare predicting anything (let alone with a 10% accuracy) about year 2060?

Please, keep in mind that in those years, the CIA expected a new ice age! Obviously, Corporate Intelligence beats the Central Intelligence Agency. I wonder why?

Many people are shocked that Exxon was aware of climate change, as early as 1977. Allow me to add to their stupor.

The first calculation of climate sensitivity that used detailed measurements of absorption spectra, as well as the first calculation to use a computer for numerical integration of the radiative transfer through the atmosphere, was performed by Syukuro Manabe and Richard Wetherald in 1967.

Assuming constant humidity, they computed an equilibrium climate sensitivity of 2.3 °C per doubling of CO2. [The work has been called “arguably the greatest climate-science paper of all time”. Manabe was awarded the 2021 Nobel Prize in Physics]

The carbon dioxide data on Mauna Loa constitute the longest record of direct measurements of CO2 in the atmosphere. They were started by C. David Keeling of the Scripps Institution of Oceanography in March of 1958 at a facility of the National Oceanic and Atmospheric Administration.

The conclusion is inescapable. In 1967, there was already a decade of CO2 data and experts could have estimated future levels as Exxon did in 1982.

Based on such prediction and the calculation of Syukuro Manabe, it would have been straightforward to predict Earth global temperature increase for at least the next 50 years!

Allow me to make a final point. How did Exxon manage to get away with this? Actually, it was rather easy.

They knew that people do not believe in science. And therefore they expected that people would not believe in global warming until it is being observed.

But they also knew that it would take many decades (probably as much as 40 years) before global warming increases temperature above natural fluctuations which are of the order of 0.5°C.

Therefore, they concluded that governments would not do anything before at least 2020.

And this is another absolutely correct prediction!

Facts vs Opinions

Everyone is entitled to his own opinion, but not to his own facts. The increase of CO2 level is pushing global temperature in a predictable way. That is a fact. Truth matters.

On April 29 2019, the Brussels Times wrote:

As early as in 1896, a scientist was warning against the potential negative effects of CO2 emissions, the Nobel Committee mentioned on Twitter on Monday. Svante Arrhenius was the first person to quantify the responsibility of CO2 in the greenhouse effect, in an article published in the Philosophical Magazine and Journal of Science.

Nothing could be further from the truth. Arrhenius believed that human emission of CO2 would be strong enough to prevent the world from entering a new ice age, and that a warmer earth would be needed to feed the rapidly increasing population. Here is what Arrhenius actually wrote:

A simplified first-order approximation expression for carbon dioxide forcing is:

$\Delta F=5.35 \times \ln {C \over C_{0}}$

where C is the CO2 concentration in parts per million (ppm) by volume and C0 is the reference concentration.

Radiative forcing can be used to estimate a subsequent change in steady-state (often denoted “equilibrium”) surface temperature (ΔT) arising from that forcing via the equation:

$\Delta T = \lambda \times \Delta F$

where λ is commonly denoted the climate sensitivity parameter, usually with units K/(W/m2), and ΔF is the radiative forcing in W/m2. A typical value of λ is around 0.8 K/(W/m2).

Therefore, if the CO2 mixing ratio in the atmosphere were to become double, the temperature is expected to increase by 3.0° C.

Indeed,

$\Delta T = 0.8 \times 5.35 \times \ln {2} = 2.97$ ,

usually rounded as 3.0°C.

Or to use the 2060 Exxon predictions mentioned in the introduction (540 ppm, 2.0°C):

$\Delta T = 0.8 \times 5.35 \times \ln {1.46} = 2.0$

A small mistake — When we used the values 340 (1980) and 420 (predicted by Exxon for year 2020), we obtain:

$\Delta T = 0.8 \times 5.35 \times \ln {0.22} = 0.92$

If you look at the graph, you will notice that the Exxon prediction is close to 1.0° (Maybe 0.97) which is clearly a mistake.

Obviously, the temperature line was either calculated or plotted incorrectly around year 2020. That kind of things happens when you work in secrecy…

Finally, if we use the value 340 (1980) and the now known value of 414 for year 2020, we obtain:

$\Delta T = 0.8 \times 5.35 \times \ln {0.22} = 0.84$

which is in excellent agreement with the latest measurements.

REFERENCES

“These data are made freely available to the public and the scientific community in the belief that their wide dissemination will lead to greater understanding and new scientific insights.”

https://gml.noaa.gov/webdata/ccgg/trends/co2/co2_annmean_mlo.txt

year mean unc

1976 332.03 0.12
1977 333.84 0.12
1978 335.41 0.12
1979 336.84 0.12
1980 338.76 0.12
1981 340.12 0.12
1982 341.48 0.12
1983 343.15 0.12
1984 344.85 0.12
1985 346.35 0.12
1986 347.61 0.12
1987 349.31 0.12
1988 351.69 0.12
1989 353.20 0.12
1990 354.45 0.12
1991 355.70 0.12
1992 356.54 0.12
1993 357.21 0.12
1994 358.96 0.12
1995 360.97 0.12
1996 362.74 0.12
1997 363.88 0.12
1998 366.84 0.12
1999 368.54 0.12
2000 369.71 0.12
2001 371.32 0.12
2002 373.45 0.12
2003 375.98 0.12
2004 377.70 0.12
2005 379.98 0.12
2006 382.09 0.12
2007 384.03 0.12
2008 385.83 0.12
2009 387.64 0.12
2010 390.10 0.12
2011 391.85 0.12
2012 394.06 0.12
2013 396.74 0.12
2014 398.87 0.12
2015 401.01 0.12
2016 404.41 0.12
2017 406.76 0.12
2018 408.72 0.12
2019 411.66 0.12
2020 414.24 0.12

Land-Ocean Temperature Index (C)

Year No_Smoothing Lowess(5)

1976 -0.10 0.04
1977 0.18 0.08
1978 0.07 0.12
1979 0.17 0.17
1980 0.26 0.20
1981 0.32 0.21
1982 0.14 0.22
1983 0.31 0.21
1984 0.16 0.21
1985 0.12 0.22
1986 0.18 0.24
1987 0.32 0.27
1988 0.39 0.31
1989 0.27 0.33
1990 0.45 0.33
1991 0.41 0.33
1992 0.22 0.33
1993 0.23 0.33
1994 0.32 0.34
1995 0.45 0.37
1996 0.33 0.40
1997 0.46 0.42
1998 0.61 0.44
1999 0.38 0.47
2000 0.39 0.50
2001 0.54 0.52
2002 0.63 0.55
2003 0.62 0.59
2004 0.54 0.61
2005 0.68 0.62
2006 0.64 0.63
2007 0.67 0.64
2008 0.54 0.64
2009 0.66 0.64
2010 0.72 0.65
2011 0.61 0.67
2012 0.65 0.70
2013 0.68 0.74
2014 0.75 0.79
2015 0.90 0.83
2016 1.02 0.88
2017 0.92 0.91
2018 0.85 0.92
2019 0.98 0.93
2020 1.02 0.94

=
